Customizable Ceramic Plunger for High Insulation and Long Operating Life in Heat Resistant Application

Brand Name : HENGYUAN

Model Number : Ceramic Plunger

Certification : CE,UL

Place of Origin : WUXI JIANGSU CHINA

MOQ : 100

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 5000 PCS/WEEK

Delivery Time : 20 DAYS

Packaging Details : Carton

Material : Ceramic Plunger

Color : White

Difficulty Of Disassembly : Easy To Disassemble

Accuracy : High Precision

OEM,ODM : Acceptable

Orgin : WUXI JIANGSU CHINA

MOQ : 100

Package : Carton

Contact Now

Customizable Ceramic Plunger for High Insulation and Long Operating Life in Heat Resistant Application

Characteristics of ceramic plunger:

(1) The surface of the inner cavity adopts a fluid structure, with no dead corners or grooves. The inner cavity surface and plunger surface are processed to a mirror surface using advanced high-precision internal and external cylindrical grinders, and the outer surface is vibration polished for easy cleaning and disinfection.
(2) The pump body structure adopts fine sealing with the product structure, making it easy to disassemble.
(3) This type of product has undergone corrosion resistance, acid and alkali resistance safety performance testing, and its various indicators have reached the level of similar foreign products.

Naterial Unit

A95%

Alumina Ceramics

A97%

Alumina Ceramics

A99%

Alumina Ceramics

A99.7%

Alumina Ceramics

Density g/cm³ 3.6 3.72 3.85 3.85
Flexural Strength Mpa 290 300 350 350
Compressive Strength Mpa 3300 3400 3600 3600
Modulus of Elasticity Gpa 340 350 380 380
Impact Resistance MPam1/2 3.9 4 5 5
Weibull Modulus M 10 10 11 11
Vickers Hardulus HV0.5 1800 1850 1900 1900
Thermal Expansion Coefficient 10-6K-1 5.0-8.3 5.0-8.3 5.4-8.3 5.4-8.3
Thermal Conductivity W/Mk 23 24 27 27
Thermal Shock Resistance △T℃ 250 250 270 270
*Maximum Use Temperature 1600 1600 1650 1650
Volume Resistivity at 20℃ Ω ≥1014 ≥1014 ≥1014 ≥1014
Dielectric Strength KV/mm 20 20 25 25
Dielectric constant εr 10 10 10 10
